Jining Tongzhao Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of medium pressure crawler drilling rig in China. If you're going to wholesale durable medium pressure crawler drilling rig made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.
Products Description
But on construction sites across Central Asia, it is the most hassle-free, rugged, and undemanding unit you can find.
High-pressure systems have their advantages, but medium-pressure systems offer stability. For a working machine, stability is far more important than sheer brute force.
Compared to high pressure, medium pressure
|
Comparison Item |
High-Pressure System (30–40 MPa) |
Medium-Pressure System (20 MPa) |
|
Hose Lifespan |
Prone to ruptures; components require replacement every six months. |
Reliable for 2–3 years of operation. |
|
Hydraulic Oil Temperature |
Prone to overheating; requires high-quality hydraulic fluid. |
Operates at low temperatures, so standard oil is sufficient. |
|
Maintenance Difficulty |
Requires a specialized technician for maintenance. |
Can be serviced by local mechanics. |
|
Spare Parts Price |
Expensive, and parts must be imported. |
Affordable, with a wide availability of standard parts. |
|
Oil Quality Requirements |
Requires the use of high-grade hydraulic oil. |
Runs effectively on standard Grade 46 oil. |
Product Specification
|
Parameter |
Specification |
|
Chassis |
8-ton excavator chassis |
|
Travel Motor |
TM10 |
|
Diesel Engine |
Yuchai 6105 / Yuchai 4015 |
|
Power Head |
Dual hydraulic motor / Five-star motor |
|
Flow Rate |
80-158 L/min |
|
Hydraulic Oil Pressure |
20 MPa |
|
Boom |
Front/back and angle adjustable |
|
Pressurization System |
Hydraulic motor |
|
Travel Speed |
2.5-3 km/h |
|
Cooling System |
Dual electronic hydraulic oil radiators |
|
Drilling Depth |
3 m (customizable) |
|
Drilling Diameter |
300-500 mm |
|
Machine Weight |
Approx. 5000 kg |
|
Chassis Length |
3000 mm |
|
Chassis Dimensions |
3000×2200 mm |
Many seasoned veterans in the construction industry understand a fundamental truth: high pressure isn't a cure-all; in fact, medium pressure often proves to be more durable.
Many sites have purchased high-pressure drilling rigs, only to face constant issues: hydraulic hoses bursting every few days, hydraulic fluid overheating and turning black, and repairs causing week-long delays.
Our Medium Pressure Crawler Drilling Rig adheres to one simple principle: 20 MPa medium pressure-it's sufficient, rugged, easy to repair, and not finicky.
Its biggest difference compared to high-pressure rigs is this: it doesn't compete on pressure; it competes on stability.
20 MPa Hydraulic Pressure: Neither too high nor too low-it's just right. Hoses won't bulge, fittings won't leak, and the hydraulic pump won't suffer from premature wear.
80–158 L/min Flow Rate: A medium-pressure, high-flow design ensures rapid operation; it won't feel sluggish just because the pressure is lower.
Dual Hydraulic Motors + Five-Star Motor: While the pressure isn't high, the torque certainly is-capable of handling everything from soft soil to crushed rock.
Dual Electronic Hydraulic Oil Coolers: Medium-pressure systems naturally generate less heat than high-pressure ones; with the addition of dual cooling units, you can work continuously even in the heat of summer.
The Practical Benefits of a Medium Pressure Drilling Rig in the Field
Unafraid of Poor-Quality Local Oil: High-pressure rigs using standard hydraulic oil will foam up and degrade within three days. Our medium-pressure machine runs perfectly fine on standard No. 46 hydraulic oil.
Easy to Repair-Any Mechanic Can Do It: High-pressure systems require specialized tools and diagnostic software to adjust parameters. Our medium-pressure system is just like an excavator-any local heavy-equipment mechanic could fix it with their eyes closed.
Affordable and Accessible Spare Parts: Hoses, fittings, and seals all use universal specifications, so you won't have to wait for parts to be shipped directly from the manufacturer.
Easy to Start in Winter: Medium-pressure systems can still operate even when the hydraulic fluid thickens in cold weather, whereas high-pressure rigs often stall out when starting from cold.
No Overheating Issues in Summer: The 20 MPa system generates very little heat to begin with, and with the dual electronic cooling system, it keeps running smoothly even in scorching temperatures of 40–50°C.
Applications
- Photovoltaic Piling
- Highway Guardrail Holes
- Wire Mesh Fence Post Holes
- Small to Medium-scale Drilling Projects
- Remote job sites with limited maintenance facilities.
