Products Description
Road guardrails serve as a critical line of defense for ensuring traffic safety; consequently, the efficiency, precision, and structural integrity of guardrail pile installation directly determine the overall quality of road safety infrastructure projects. Traditional guardrail construction methods have long plagued work crews with issues such as difficult equipment transport, poor adaptability to varying geological conditions, low operational efficiency, and high labor costs. As a specialized piece of piling machinery, the wheeled guardrail pile driver directly addresses these construction pain points. With its versatile performance capabilities, it has emerged as a core piece of equipment for guardrail installation on highways, municipal roads, and rural routes, thereby comprehensively upgrading the entire construction experience.
|
Loader model |
ZL-936 |
|
Engine model |
4108 Pressurization |
|
Overall machine weight (kg) |
4400 |
|
Rated power (kw) |
78 |
|
Rated speed (r/min) |
2400 |
|
Brake system |
Dual-pump air cut-off brake |
|
Overall dimensions (length x width x height) (mm) |
5600X2400X2750 |
|
Automatic transmission |
|
|
Oil pump model |
High strength 40/40 |
|
Pressure (pm) |
16 |
|
Railway track model |
125 I-beam steel |
|
125 I-beam steel thickness (mm) |
8 |
|
Hydraulic operating valve model |
15 |
|
Hydraulic operating valve pressure (pma) |
16 |
|
The pipe is made of multi-layer steel wire H-head high-pressure oil-resistant pipe. |
|
|
Hammer head model |
75 |
|
Air compressor |
10/8 |
|
Impactor |
110 |
|
Drill bit |
1 piece |
Flexible Relocation: Bidding Farewell to Geographic Constraints
Equipped with a dedicated mobile chassis and featuring a four-wheel-drive design, the wheeled guardrail pile driver offers exceptional mobility and agile steering. It requires no tow truck for transport, allowing it to drive autonomously directly along construction zones, rural paths, and winding mountain roads-effortlessly facilitating transitions between various job sites. Whether undertaking long-distance, linear guardrail installation on highways or performing scattered guardrail repairs on rural roads, the machine can reach the site rapidly. This eliminates the cumbersome processes of equipment disassembly and transport, significantly enhancing operational mobility and making it particularly well-suited for scattered projects spanning multiple locations or distinct regions.
All-Around Performance: Adapting to All Geological Conditions.
Breaking through the limitations of single-function machinery, this device integrates three core capabilities-hydraulic piling, hydraulic pile extraction, and front-mounted drilling-to truly achieve "one machine, multiple uses." For standard geological conditions such as soft soil or clay, the hydraulic impact hammer delivers powerful, instantaneous force to rapidly drive steel guardrail piles to the required depth, ensuring high vertical alignment and structural stability. When encountering complex terrain-such as hard rock, frozen ground, or gravel-the drilling function can be activated to pre-drill pilot holes before piling begins, thereby preventing pile bending or breakage and ensuring the smooth progression of the project. Furthermore, for guardrail removal and renovation projects, the pile extraction function effortlessly removes old piles; this fully mechanized process eliminates the need for manual brute force, ensuring both safety and efficiency.
Stable and Durable: Reducing Construction and Maintenance Costs.
The machine body is constructed from thickened, welded steel, featuring a robust structure and exceptional load-bearing capacity that resists deformation even during prolonged, high-intensity operations. The core hydraulic system utilizes components from renowned brands, ensuring superior sealing performance, stable power transmission, and an extremely low failure rate, making it highly adaptable to harsh outdoor construction environments. Furthermore, the equipment features a low operational threshold; incorporating an ergonomic handle-based control design with one-touch switching for various functions, it allows operators to begin work after only brief training-no prior professional experience is required. This enables precise control over piling depth and positioning, ensuring that guardrail installations are uniform and fully compliant with road construction standards.
With its extensive applicability, the machine meets construction requirements across a wide spectrum of scenarios. This wheeled guardrail piling machine is not only ideal for the installation and maintenance of corrugated guardrails along major thoroughfares-such as expressways, national highways, and provincial roads-but is also widely utilized for various smaller-scale piling projects, including municipal park fencing, residential community enclosures, livestock pasture fencing, and solar farm support piles. During operation, the machine generates minimal noise and pollution, thereby minimizing its environmental impact; by balancing construction efficiency with ecological requirements, it serves as an ideal choice for diverse engineering teams and road maintenance agencies.
In the current era of continuous upgrades to road infrastructure, efficient, intelligent, and practical construction equipment is the key to enhancing project competitiveness. With its core advantages of flexibility, versatility, stability, and cost-effectiveness, this wheeled guardrail piling machine perfectly resolves the various challenges inherent in guardrail construction. It not only shortens construction cycles and reduces labor requirements but also guarantees both project quality and operational Safety
